Technical data

Model No. ： ZL-SZTB6500-2(Manual automatic integration)

Motor specification： JXDRF 300 - 12400

Rated operating voltage： D/V 3.6V

Operating voltage range： 2V~4.5V(The higher the voltage, the greater the torque)

Operating current at no load at rated operating voltage： ≈20mA (At normal temperature)

Blocking current at rated operating voltage： ≈350mA（±50mA）

Output torque at rated operating voltage： ≈6.5N.M（±0.5n.m）

On (off) time at stable operating voltage： ≈20S

Gear reduction ratio： 6500:1

Waterproof  level ： No
